GermanAUTOMATIC MITER SAW FOR PVC PLASTIC PROFILES EVOM II
AUTOMATIC MITER SAW FOR PVC AND PLASTIC PROFILES – EVOM II
Hydro-pneumatic precision and maximum efficiency for cutting plastic profiles
Precise, powerful, and efficient – the new generation of industrial miter saws
The EVOM II is a fully automatic miter saw for PVC and plastic profiles, designed for precise, clean, burr-free cuts in thermoplastic materials. With its hydro-pneumatic feed system and automatic clamping technology it guarantees smooth cutting motion, exact angles and maximum repeatability – perfect for professional use in windows, doors, and façade technology.
The combination of throughput, precision and reliability makes the EVOM II the perfect solution for companies working with plastic profiles who demand the highest standards of quality and efficiency.
Hydro-pneumatic feed system for exact cuts
At the heart of the EVOM II is the hydro-pneumatic feed system which controls cutting motion uniformly and without vibration.
This technology enables precise adjustment of cutting speed to match the material – ideal for PVC, plastic, ABS, polycarbonate and similar profiles.
The pneumatic clamping cylinders fix the workpiece both vertically and horizontally, ensuring secure hold.
This clamping system prevents slippage, material distortion and vibration during cutting and significantly increases blade lifetime.
The result: clean, dimensionally accurate and melt-free cutting surfaces that require virtually no rework – even on sensitive or coated profiles.
Robust construction for industrial dependability
The EVOM II features a stable, vibration-damped cast structure that ensures smooth mechanics and exact cutting guidance.
Its massive machine body reduces oscillations to a minimum and allows consistently high cut quality – even in demanding production environments.
An integrated safety enclosure with dual-spring protective hood shields the operator reliably during operation.
Optionally, a cooling system may be installed to regulate temperature during cutting, reduce tool wear, and increase precision.
Thus the EVOM II stands for longevity, stability and process security – essential for all professional users in plastic profile processing.
Technical Specifications of the EVOM II
| Feature | Specification |
|---|---|
| Saw blade diameter | Ø 400 mm (carbide blade, specially for plastics) |
| Rotation speed | 3,000 rpm |
| Motor power | 2.2 kW / 3 HP |
| Clamping system | Pneumatic, vertical and horizontal |
| Feed system | Hydro-pneumatic |
| Voltage / frequency | 400 V / 50 Hz |
| Air pressure | 6–8 bar |
| Air consumption | 25 L/min |
| Machine dimensions (L × W × H) | 1,200 × 1,230 × 1,500 mm |
| Weight | 120 kg |
| Standard equipment | Ø 400 mm carbide blade, safety enclosure |
| Options | Cooling system, single-phase motor, speed controller |
Efficient application in plastic profile processing
The automatic miter saw EVOM II is versatile and offers highest cut quality in a wide range of applications:
Window manufacturing
Precise cutting of PVC frames and sash profiles for tight, dimensionally accurate corner joints.
Door manufacturing
Precise miter cuts for plastic frames, thresholds and connector elements.
Façade construction
Smooth and burr-free cuts in plastic panels, cover strips and cladding profiles.
Plastic processing industry
Processing of multi-chamber and composite profiles with consistent quality.
Workshops and craft operations
Ideal for businesses seeking efficiency, accuracy and safety in a compact form.
Advantages of the automatic miter saw EVOM II
-
Automatic hydro-pneumatic feed
Uniform cutting motion with constant speed for clean, precise cuts. -
Clean, burr-free cuts
Thanks to the carbide blade and precise feed control, cuts are smooth and free of melting. -
Pneumatic dual clamping
Vertical and horizontal fixation for vibration-free, safe profile processing. -
Energy-efficient and low-maintenance operation
Robust components, low air consumption and long tool life. -
CE-certified safety
Full protective cover, dual-spring hood and emergency stop system for maximum operator safety. -
Robust cast construction
Stable machine base for precise cuts and long-lived use in industrial environments.
Efficiency and productivity in every application
The EVOM II integrates industrial cutting technology, ergonomic design and high energy-efficiency.
Through its precise hydro-pneumatic control and intelligent clamping technology it boosts productivity while reducing tool wear and scrap rates.
Each machine from Evomatec is manufactured to European quality standards and CE certified. Our engineers test all relevant components – from feed mechanics to safety device – to guarantee consistently high precision and reliability.
Conclusion – Precision, safety and cost-effectiveness in perfection
The EVOM II automatic miter saw stands for top cutting precision, process stability and efficiency in the processing of PVC and plastic profiles.
With hydro-pneumatic feed technology, dual clamping system and durable construction, it offers the perfect combination of quality, comfort and productivity.
Whether for window, door or façade construction – the EVOM II is the ideal machine for clean, repeatable and cost-effective cutting operations.
Contact our team for a free consultation or a personalized quote: Click here
